Time Attendance & Access Control
- Technical Info
- Description
| User Capacity | 3000 |
| Fingerprint Capacity | 3000 |
| ID Card Capacity | 3000 optional |
| Record Capacity | 50,000 |
| Display | 2.8’’ color screen |
| Communication | TCP/IP, WiFi, USB-host |
| Standard Functions | 9 Digit User ID, T9 Input, SMS, DST, Self-Service Query, Automatic Status Switch, Ring bell, ADMS |
| Optional Functions | ID/Mifare, RS232 External Printer |
| Access Control Interface | 3rd Party Electirc Lock, Exit Button |
| Software | BioTime |
| Power Supply | DC 12V/1.5A |
| Dimension | 186*138*43.6mm (LxWxT) |
| 186*138*43.6mm (LxWxT) | 0 °C - 45 °C |
| Operating Humidity | 20% - 80% |
- Wi-Fi: WiFi module is integrated. It is working on the 2.4G radio band, and meet the IEEE 802.11b/g/n standards.
- USB: Support USB host connection to achieve data backup and management while the device is standalone.
- WDMS: Optional for devices worldwide using. Solve the device’s capacity limitation through networking via HTTP sever. Mondial devices can be connected and upload & backup data automatically. This is helpful for devices managing and monitoring.
- BioID: Using BioID Fingerprint Collector for excellent recognition rate. Dry, moist, or rough fingerprints can work well.WDMS
