| NOMINAL IMPEDANCE | 8Ω |
| SENSITIVITY | 89dB (2.83V/ 1m) |
| FREQUENCY RESPONSE | 60 - 20kHz (+/-6dB) With back can/rear enclosure |
| CROSSOVER FREQUENCIES | 2.8kHz |
| DRIVE UNITS | LF: 160mm / HF: 19mm |
| RECOMMENDED AMPLIFIER POWER | 10 - 100W |
| FEATURES | Uni-Q Array, UL2043 & UL1480-5 approved, 8Ohm or 70V: 8w, 15w, 30w, 60w, 100V: 16w, 30w, 60w |
| PRODUCT EXTERNAL DIMENSIONS | Diameter / Depth : 275mm (10.83in.) / 188mm (7.40in.) |
| CUT-OUT DIMENSIONS | Diameter : 240mm (9.45in.) |
| MOUNTING DEPTH FROM SURFACE | With back can : 185mm (7.28in.) |
| UNIT MEASUREMENT | Piece |
