LCD keypad for INTEGRA control panels

  •  Technical Info
  •  Description
Two-way wireless technology Yes
Blue Wave Technology Yes
Dual element pyroelectric sensor Yes
Tamper protection Front, rear and external tamper switch
Intergrated walk test buzzer Yes
Separate LED indication Top: Microwave, PIR 1 and alarm Bottom: PIR 2
Signal Strength Indicators (SSI) Yes
Anti-Sway Analytics Yes
Weatherproof IP55 rated
Adjustable sensitivity High or low range
Casing 3mm polycarbonate 0.4mm HDPE in lens area
Maximum range 12 metres
Volumetric coverage 90° coverage
Dual technology Yes
Animal immunity Up to 35kg 1 - 1.5m (mounting height of detector)
Battery type 2x 3V 4700mAh Lithium battery packs (BATT-ES1)
Battery life Up to 3 years
Battery capacity 4700mAh
Environmental class IV
  •  Detection range 12m
  •  Volumetric coverage 90°
  •  Tri-Signal Detection Logic
  •  Adjustable PIR/MW range
  •  Dual-Vision Pet Immune (up to 35kg)
  •  Up to 1.6km two-way wireless
  •  Anti-Sway Analytics
  •  Blue Wave Technology (BWT)
  •  IP55 heavy duty design
  •  Flexible installation and easy setup
