GXP2140 IP Desktop Phone
GXP2140 IP Desktop Phone
- HD audio on speakerphone and handset, 5 programmable context sensitive soft keys
- Supports 4 lines, 4 SIP accounts and 5 way voice conferencing
- Compatible with GXP2200 LCD extension module (GXP2200 EXT)
- 4.3 inch (480x272) color screen LCD
- Dual Gigabit ports, integrated PoE
Specification
 |
|
| Network Interfaces | Dual switched auto sensing 10 / 100 / 1000 Mbps Gigabit Ethernet ports with integrated PoE |
| Protocols / Standards | SIP RFC3261, TCP / IP / UDP, RTP / RTCP, HTTP / HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TELNET, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR069, 802.1x, TLS, SRTP, IPv6, CDP / SNMP / RTCP-XR |
| Graphic Display | 4.3 inch (480x272) TFT color LCD |
| Bluetooth | Yes, Bluetooth V2.1 |
| Feature Keys | 4 line keys with up to 4 SIP accounts, 5 programmable context sensitive softkeys, 5 navigation / menu keys, 11 dedicated function keys for: MESSAGE (with LED indicator), PHONEBOOK, TRANSFER, CONFERENCE, HOLD, HEADSET, MUTE, SEND / REDIAL, SPEAKERPHONE, VOL+, VOL- |
| Voice Codecs | Support for G.729A/B, G.711μ/a-law, G.726, G.722 (wide band), G723.1, iLBC, Opus, and iLBC, in band and out of band DTMF (in audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC |
| Auxiliary Ports | RJ9 headset jack (allowing EHS with Plantronics headsets), USB, extension module port |
| Telephony Features | Hold, transfer, forward, 5-way conference, call park, call pickup, shared call appea rance (SCA) / bridged line appearance (BLA), downloadable phonebook (XML, LDAP, up to 2000 items), call waiting, call log (up to 500 records), customization of screen, off hook auto dial, auto answer, click to dial, flexible dial plan, hot desking, personalized music ringtones and music on hold, server redundancy and fail over |
| Sample Applications | Weather, currency, news, XML |
| HD Audio | Yes, both on handset and speakerphone |
| Extension Module | Yes, can power up to 4 GXP2200EXT modules which features a 128x384 graphic LCD, 20 quick dial / BLF keys which dual color LED, 2 navigation keys, and less than 1.2W power consumption per unit. |
| Base Stand / Wall Mountable | Yes, allow 2 angle positions |
| QoS | Layer 2 (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS |
| Security | User and administrator level passwords, MD5 and MD5 sess based authentication, AES based secure configuration file, SRTP, TLS, 802.1x media access contro |
| Multi language | English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, simplified and traditional Chinese, Korean, Japanese and more |
| Upgrade / Provisioning | Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR069 or encrypted XML configuration file, FTP / FTPS |
| Power & Green Energy Efficiency | Universal power adapter included, Input: 100-240V, Output: +12V, 1.0A, Integrated Power over Ethernet (802.3af), Max power consumption: 6W (without GXP2200EXT), 10W (with 4 cascaded GXP2200EXTs) |
| Physical | Dimention: 228mm (W) x 206mm (L) x 46.5mm (H), Unit weight: 0.98kg, Package weight: 1.55kg |
| Temperature and Humidity | 0 ~ 40ºC (32 ~ 104ºF ), 10 ~ 90% (non condensing) |
| Package Content | GXP2140 phone, handset with cord, base stand, universal power supply, network cable, Quick Start Guide |
