| System | Main Processor | Embedded Micro Processor |
| Operation System | Embedded LINUX OS |
| Video | |
| Video Compression | H.264 |
| Image Sensor | 1/3” 1.3MP CMOS |
| Lens | Pinhole |
| Day/Night | Color Image |
| Audio | |
| Audio Compression | G.711 |
| Audio Input | All-direction Microphone |
| Audio Output | Built-in Loudspeaker |
| Bidirectional Talk | Support Dual-way Bidirectional talk |
| Display | |
| LCD Screen | 7“ 800x480, Capacitive |
| Operation Mode | |
| Input | Single Mechanical Button |
| Reader | Mifare Card |
| Interface | |
| Door Control | 1 |
| Alarm In | 2(1ch unlock button, 1ch feedback) |
| Alarm Out | 1 |
| RS485 | -- |
| Network | |
| Ethernet | 10M/100Mbps Self-adaptive |
| Network Protocol | TCP/IP |
| General | |
| Memory Slot | Micro SD, Max 32GB |
| Installation | Surface |
| Power | Supply directly by VTNS1006A-2 |
| Power Consumption | Standby =1.5W, Work =7W |
| Working Temperature | ?10°C~+55°C |
| Relative Humidity | 10%~90%RH |
| Dimensions | 200.0mm×136.0mm×22.0mm |
| Weight | 0.4Kg |
